This is an example of a standard wired layout (Built to ANSI C37.21 Control Switchboard).
- Circuits are clearly identified.
- Wire duct for incoming customer wires done without hardware wire supports allowing quicker customer installation (NEMA screw-type terminals accept ring terminal or fork style lugs).
Quality Control:
Each circuit is tested for continuity and logic function. Copy of documentation is shipped with the panel.
